INTRODUCTION TO CURVES

Magnetic system with metal strip: "EXTRA" curves Regal has developed a magnetic curve retention system for dry-running applications. The system, sets new performance standards in magnet curve technology due to the inclusion of a unique metal strip mounted in the inside bearing face of the top section. This area is constantly under load due to the pressure/speed factor. Main advantages: Extreme dissipation of heat significantly reduces wear. Under test conditions, lowest noise decibel levels were recorded. "Extra" curves are strongly recommended with plastic chains only! Go to:

BEVEL TAB MAGNETIC

Secure chain retention: + +++ ++ Support in return part: - ++ + Chain can be lifted for cleaning: ++ - +++ Jamming due to foreign particles: + - ++

COMPARISON OF CURVE SYSTEMS: BEVEL: TAB: MAGNETIC:

Nolu-S (R) material are a unique compound of UHMWPE and a solid lubricant. They drastically reduce the coefficient of friction, maintaining the characteristics of UHMWPE. Nolu-SR matereial have a better thermal conductivity compared with UHMWPE. Benefits and features of Nolu-S(R) material: They makes very high speeds possible, especially when running dry. They has an extremely low coefficient of friction. They reduces noise and squeaking. They reduces chain pull. They extends the life of the chain. They does not damage and scratch the surface of PET. They reduces the consumption of energy. They is a UHMWPE with a solid lubricant.

HDPE 500 UMHW-PE1000 UMHW-PE1200 Nylatron GSM/NSM Nolu-S (R)

SPECIAL CURVES FOR DRY RUNNING APPLICATIONS

Design and functionality: Dual Magnetic System curves have the magnets positioned on the outside of the centre line radius of each track which results in a more effective magnetic field through the curve.

R Magnet

REGAL OFFERS A COMPLETE RANGE OF CURVES AND STRAIGHT TRACKS, DESIGNED FOR ALL POSSIBLE CONVEYOR APPLICATIONS. BELOW A BRIEF OVERVIEW OF THE VARIOUS CHARACTERISTICS.

Coefficient of friction comparison of materials

INDEX CURVES GO TO:

Index curve and straight track for TAB Index magnetic curves

UHMWPE Solid lubricant

TOPTRAC magnetic curve System Plast TopTrac system is a new concept for magnetic curves, developed by Regal. The Nolu-SR interchangeable wear strips allow for higher speeds and loads. New magnet design and material results in a homogenous magnetic field, which improves product stability and productivity. The Nolu-SR wear strips can be quickly replaced, while curve remains fitted in the system.

MAGNETIC

NYLATRON is believed to be the trademark and/or trade name of Quadrant EPP USA Inc. and is not owned or controlled by Regal Beloit Corporation.

Revision 001
